CPVC Pipes and Fittings for Hot and Cold Water

CPVC (chlorinated polyvinyl chloride) is a strong, durable material that has been successfully used in plumbing applications around the world for more than 50 years.

1.Delivery: 10-30 days depending on the total quantity.
2.Packing: 4m or 6m/ Pcs for straight, with plain ends or SCJ end.
3.CO (Certificate of Origin): China, CO could be provided by free.
4.Products Inspection: Raw material, production process, delivery or third-party factory inspection
5.MOQ: Trial Order or 1*20ft containers by mixed loading.

Send E-mail Get Price

Introduction

Specifications

Application

Download

Quick Details of Chlorinated Polyvinyl Chloride(C-PVC) pipes system for hot and cold water

Products details information
Product name	Chlorinated Polyvinyl Chloride(C-PVC) pipes system for hot and cold water
Brand	Bingo pipeline(Customer brand is available)
Dia Ranges	DN20-800mm(1/2 inch-32 inch)
Pressure Class	from PN8 to PN25 and Non Pressure PVC Pipe
Raw material	C PVC...
Application	PVC Pipes& fittings for drinking water, fresh water, portable water...
Color	Grey, Blue, others colors is option
Standards	EN 1401, EN ISO 1452, EN ISO 15493, EN 1767, ISO4422, ASTM D1785, BS 3505...
Matching products	C PVC fittings, Solvent Cement fittings, Rubber Ring Joints, Flanges, Glue and tools, etc.
Company/Factory Strength
Production Capacity	120*40ft containers/month
Sample	Free sample could be provided
Quality	QA & QC system, Ensure traceability of each process
Warranty	50 years with normal use
Certificates	ISO9001, OHSAS 18001, ISO14001,CE...
Delivery time	5-30 days, depending on the quantity
Test/Inspection	National Standard Laboratory/ Pre-delivery inspection
Service	Research, Design, manufacture, Test, Sales, Solution Providing, After-sale service
Management	Effective 8S Management System
No. of employees	More than 300 people

Welcome customers to visit the factory, or third party factory inspection is acceptable.

Description of Chlorinated Polyvinyl Chloride(C-PVC) pipes system for hot and cold water

CPVC is a thermoplastic made by further chlorination of the polyvinyl chloride resin. This means its chemical composition is two carbon atoms bonded to each other with two hydrogen atoms and two chlorine atoms bonded to this double carbon unit. This molecule links with others to form polymer chains of CPVC. CPVC delivers superior resistance to degradation and provides a long service lifespan. In fact, the first piping systems using CPVC occurred in 1959 and are still working without a problem.

CPVC pipes are sized in two ways -- nominal pipe size (NPS references the diameter of the interior hole of the pipe) and copper tube size (CTS references the outside diameter of the copper tube size). Often, pipes using the NPS system are light gray, and pipes using CTS system are yellow. Both types of pipe will have their specifications printed on the side. And the pipe are packaged in straight length for the diameter for Sch 40 or Sch 80 piping is available up to a maximum diameter of 24 inches.

Chlorinated Polyvinyl Chloride (CPVC) is a thermoplastic pipe and fitting system made with CPVC compounds meeting the requirements of ASTM Class 23447 as defined in ASTM Specification D1784. PVC pipes could only be used for cold water system, but C PVC service the temperatures can be extended by 60-70°F, is available for both cold water and hot water distribution.

The primary method of joining CPVC piping systems is solvent-cementing for glue installation.

Advantages of Chlorinated Polyvinyl Chloride(C-PVC) pipes system for hot and cold water

Following are just a few of the reasons why are CPVC pipe and fittings are widely used around the world:

Safe, Clean Water Quality: Qualified CPVC potable water system does not transfer any harmful and dangerous products to the drinking water it transports. Our material is approved for all potable water systems, and our compounds do not contain plasticizers, flame retardants, bio-stabilizers or anti-static agents.

Joint Strength: CPVC pipe and fittings are fused together using solvent cement. Solvent cement is a substance that chemically fuses a pipe to a fitting at the molecular level. Unlike glue used in other piping systems, solvent cemented joints become the strongest part of the pipe system, and if properly installed don’t break apart.

Chlorine Resistance: Chlorine-based disinfectants, especially chlorine dioxide can cause pipe failures in PPR (green pipe), PEX and metallic pipes. However, CPVC is unaffected by the chlorine and will never fail thanks to the additives used to keep your water clean and safe.

Biofilm Resistance: Water distribution systems are ideal for bacterial growth, but CPVC helps to keep water pure. Multiple international studies have confirmed that CPVC consistently outperforms copper and all other plastic piping materials, especially PPR, with regard to its ability to resist the formation of biofilms.

Fire Resistance: CPVC is fire resistant and will not support combustion. In other words, CPVC won’t help to spread a fire, unlike other plastics that can catch fire and continue to burn after the source has been removed.

Specification of Chlorinated Polyvinyl Chloride(C-PVC) pipes system for hot and cold water

Nom. Pipe Size (in.)	O.D. (in.)	Schedule 40 Dimensions(in)				Schedule 80 Dimensions(in)
Nom. Pipe Size (in.)	O.D. (in.)	Average I.D.	Min. Wall	Nom. Wt./Ft.	Max. W.P	Average I.D.	Min. Wall	Nom. Wt./Ft.	Max. W.P
1/4	0.540	0.344	0.088	0.096	780	0.282	0.119	0.117	1130
3/8	0.675	0.473	0.091	0.128	620	0.403	0.126	0.162	920
1/2	0.840	0.602	0.109	0.190	600	0.526	0.147	0.238	850
3/4	1.050	0.804	0.113	0.253	480	0.722	0.154	0.322	690
1	1.315	1.029	0.133	0.371	450	0.936	0.179	0.473	630
1-1/4	1.660	1.360	0.140	0.502	370	1.255	0.191	0.654	520
1-1/2	1.900	1.590	0.145	0.599	330	1.476	0.200	0.793	470
2	2.375	2.047	0.154	0.803	280	1.913	0.218	1.097	400
2-1/2	2.875	2.445	0.203	1.267	300	2.290	0.276	1.674	420
3	3.500	3.042	0.216	1.660	260	2.864	0.300	2.242	370
3-1/2	4.000	3.521	0.226	1.996	240	3.326	0.318	2.735	350
4	4.500	3.998	0.237	2.363	220	3.786	0.337	3.277	320
5	5.563	5.016	0.258	2.874	190	4.768	0.375	4.078	280
6	6.625	6.031	0.280	4.164	180	5.709	0.432	6.258	280
8	8.625	7.942	0.322	6.268	160	7.565	0.500	9.506	250
10	10.750	9.976	0.365	8.886	140	9.493	0.593	14.095	230
12	12.750	11.889	0.406	11.751	130	11.294	0.687	19.392	230
14	14.000	13.073	0.437	13.916	130	12.410	0.750	23.261	220
16	16.000	14.940	0.500	18.167	130	14.213	0.843	29.891	220
18	18.000	16.809	0.562	22.965	130	16.014	0.937	37.419	220
20	20.000	18.743	0.593	29.976	120	17.814	1.031	45.789	220
24	24.000	22.544	0.687	37.539	120	21.418	1.218	64.959	210

Other specifications have not been shown on our dimension chart, please CONTACT US for more information

Applications of Chlorinated Polyvinyl Chloride(C-PVC) pipes system for hot and cold water

- CPVC or Chlorinated Polyvinyl Chloride is a thermoplastic polymer used for plumbing applications in residential, commercial, and industrial buildings. CPVC pipes are bendable and exhibit fire-retardant properties, which means they can slow down or stop the spread of fire and are used in fire sprinkler systems.

- CPVC pipe resists most acids, bases, salts, aliphatic solutions, oxidants, and halogens. The most common applications for CPVC pipe is in chemical processing, plating, high purity applications, potable water systems, wastewater treatment plants, and other industrial corrosive media applications.

CPVC pipes are used in industrial plumbing for chemicals. They are used in the transportation of chemicals and hot corrosive fluids that includes a wide range of inorganic acids, bases used in chemical processing.
